Trane / American Standard FAN03159 Fan Blade – 26" Diameter, 4-Blade, 26° Pitch, CCW, 1/2" Bore

Trane / American Standard FAN03159 Fan Blade – 26" Diameter, 4-Blade, 26° Pitch, CCW, 1/2" Bore

Low stock: 1 left

Regular price $385.00 USD
Regular price Sale price $385.00 USD
Sale Sold out
Shipping calculated at checkout.

Trane FAN03159 OEM fan blade replaces FAN3159. 26" diameter, 4 blades, 26° pitch, CCW rotation and 1/2" bore for compatible Trane HVAC unit

  • Current FAN03159 replaces legacy FAN3159

  • 1/2-inch center bore

  • Counterclockwise CCW rotation

  • 4-blade configuration with 26° pitch

  • 26-inch diameter OEM Trane fan blade

Please visit our store for pick up.

Quantity

safe & secure Checkout

Fast & Tracked Delivery
30 Day money back guarantee

Specifications

Trane FAN03159 FAN3159 Fan Blade Specifications

description

The Trane / American Standard FAN03159 Fan Blade is a genuine OEM replacement fan blade designed for select Trane and American Standard HVAC equipment. It features a 26-inch diameter, 4-blade configuration, 26° blade pitch, counterclockwise (CCW) rotation, and 1/2-inch bore.

The current FAN03159 replaces the older FAN3159 part number. Manufacturer replacement information indicates that the part number was changed without modification to the replacement product.


Key Features & Function

 Genuine Trane OEM Fan Blade

 26-Inch Diameter

 4-Blade Configuration

 26° Blade Pitch

 Counterclockwise (CCW) Rotation

 1/2-Inch Bore

• Designed for compatible Trane and American Standard HVAC equipment

• Used in select packaged and commercial HVAC applications

• Helps maintain proper condenser airflow

 Current Part # FAN03159

 Previous Part # FAN3159


Product Details & Key Specifications

Specification Details
Brand Trane / American Standard
Current Part Number FAN03159
Previous Part Number FAN3159
Product Type HVAC Fan Blade
Diameter 26"
Number of Blades 4
Blade Pitch 26°
Rotation Counterclockwise (CCW)
Bore Size 1/2"
Application HVAC
OEM / Aftermarket OEM
Compatible Brands Trane / American Standard
Typical Equipment Packaged Unit / RTU / Heat Pump

🛠️ HVAC Depot Pro Tip: Don't Confuse FAN03159 With Similar 26" Trane Blades

Trane uses several 26-inch fan blades with different blade counts and pitches. FAN03159 specifically requires:

 26" Diameter

 4 Blades

 26° Pitch

 CCW Rotation

 1/2" Bore

Before replacing the blade, also verify the motor RPM, horsepower, shaft size, fan position, and shroud clearance.

A 26-inch blade with a different pitch can alter airflow and increase or decrease motor loading.


Cross-Reference & Superseded Part Numbers

Current OEM Part Number

FAN03159

Previous / Legacy Part Number

FAN3159

Common Search Variations

FAN-03159

FAN-3159

Trane FAN03159

Trane FAN3159

American Standard FAN03159

American Standard FAN3159

The older FAN3159 is obsolete and has been replaced by FAN03159.


Equipment & Model Compatibility

The FAN03159 is documented in numerous Trane packaged and commercial HVAC configurations, including select TSC, THC, YSC, and WSC series equipment.

Documented examples include:

TSC072AWECA

TSC090F3E0A0000

THC072F3E0A

THC074F4RKA

THC120A4RKA

YSC072F3ELA

YSC090AWELA

YSC102F4RHA

WSC072E3R0A00000000000000

Because Trane can use different fan assemblies within the same equipment family, verify the complete model and serial number before ordering.
